Product Summary
The ATMEGA8A is a Programmable Flash. The ATMEGA8A is a low-power CMOS 8-bit microcontroller based on the AVR RISC architecture. By executing powerful instructions in a single clock cycle, the ATMEGA8A achieves throughputs approaching 1 MIPS per MHz, allowing the system designer to optimize power consumption versus processing speed.
Parametrics
ATMEGA8A absolute maximum ratings: (1)Operating Temperature : -55℃ to +125℃; (2)Storage Temperature : -65℃ to +150℃; (3)Voltage on any Pin except RESET with respect to Ground : -0.5V to VCC+0.5V; (4)Voltage on RESET with respect to Ground : -0.5V to +13.0V; (5)Maximum Operating Voltage : 6.0V; (6)DC Current per I/O Pin : 40.0 mA; (7)DC Current VCC and GND Pins : 300.0 mA.
Features
ATMEGA8A features: (1)Two 8-bit Timer/Counters with Separate Prescaler, one Compare Mode; (2)One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode; (3)Real Time Counter with Separate Oscillator; (4)Three PWM Channels; (5)Byte-oriented Two-wire Serial Interface; (7)Programmable Serial USART; (8)Master/Slave SPI Serial Interface; (13)Programmable Watchdog Timer with Separate On-chip Oscillator; (9)On-chip Analog Comparator; (10)Power-on Reset and Programmable Brown-out Detection; (11)Internal Calibrated RC Oscillator; (12)External and Internal Interrupt Sources; (13)Five Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, and Standby.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ATMEGA8A |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
ATMEGA8A-AN |
Atmel |
8-bit Microcontrollers (MCU) AVR 8KB FL 512B EE 1KB SRAM 16 MHZ GRN |
Data Sheet |
|
|
||||||||||||
 |
ATMEGA8A-AU |
Atmel |
8-bit Microcontrollers (MCU) AVR 8KB, 512B EE 16MHz 1KB SRAM |
Data Sheet |
|
|
||||||||||||
 |
ATMEGA8A-MN |
Atmel |
8-bit Microcontrollers (MCU) AVR 8KB FLSH 512B EE 1KB SRAM-16MHz 105C |
Data Sheet |
|
|
||||||||||||
|
ATMEGA8A-AUR |
Atmel |
8-bit Microcontrollers (MCU) AVR 8KB FLSH 512B EE 1KB SRAM-16MHz |
Data Sheet |
|
|
||||||||||||
|
ATMEGA8A-ANR |
Atmel |
8-bit Microcontrollers (MCU) AVR 8KB FLSH 512B EE 1KB SRAM-16MHz 105C |
Data Sheet |
|
|
||||||||||||
|
ATMEGA8A-MU |
Atmel |
8-bit Microcontrollers (MCU) AVR 8KB, 512B EE 16MHz 1KB SRAM |
Data Sheet |
|
|
||||||||||||
 |
ATMEGA8A-PU |
Atmel |
8-bit Microcontrollers (MCU) AVR 8KB, 512B EE 16MHz 1KB SRAM |
Data Sheet |
|
|
||||||||||||
