Product Summary

The T1021NL is a T1/CEPT/ISDN-PRI transformer.

Parametrics

T1021NL absolute maximum ratings: (1)Metallic Voltage: 800 V peak, 10/560 μsec; (2)Longitudinal Voltage: 2,400 V peak, 10/700 μsec; (3)Frequency: 50-100 KHz.

Features

T1021NL features: (1)RoHS peak reflow temperature rating 245℃; (2)Single port T1/E1 solution; (3)Configurable for TP and Coax cable termination; (4)Transfer-molded, IC-grade packaging; (5)UL1950 approved to basic isolation.

Diagrams

T1021NL block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
T1021NL
T1021NL

Pulse

Transformers Audio & Signal TRANSFORMER QUAD

Data Sheet

0-225: $1.40
225-500: $1.24
500-1000: $1.16
1000-2000: $1.12
T1021NLT
T1021NLT

Pulse

Transformers Audio & Signal TRANSFORMER QUAD

Data Sheet

0-275: $2.05
275-500: $1.89
500-600: $1.89
600-1000: $1.78
